[어보브반도체(주)]

▶ A34L716 : Max. 256KB Flash memory/ 24KB SRAM/ 32KB Data Flash memory

◎ Operating Frequency : 32MHz
◎ Operating Voltage : 1.8V ~ 3.6V
◎ Operating Temperature : -40℃ ~ +85℃
◎ Key Features : USB FS / LCD driver/ RTC/ LP UART/ 12-bit ADC (1Msps)/ OPAMP/ 12-bit DAC/ 128-bit Unique ID
◎ Power Consumption : Run mode: 247uA/MHz, Deep sleep mode: 1.79uA (with RTC), 1.4uA (All off)
◎ Communication: USART(2-ch)/ UART(1-ch)/ LP UART(2-ch)/ I2C(2-ch)/ SPI(2-ch)/ USB FS
◎ Potential Application : Mass consumer & Small home appliances / Various controllers & modules / Other home appliances / Portable healthcare / Portable consumer electronics / Battery operated applications
