[어보브반도체(주)]

Devices in ABOV Semiconductor’s Cortex®-M0+-based 32-bit G1 Series deliver optimal functions for home appliances and consumer electronics. The S1 series supports 128 KB of code flash and 4 KB of data flash to provide system scalability.

▶ A31S134 : 128KB Flash memory/ 4KB Data Flash/ 16KB SRAM/ 8-High current port/ 2-ch DMA; Communication: USART(Max. 3-ch)/ UART(Max. 2-ch)/ I2C(Max. 3-ch)

○ Operating Frequency : 32MHz
○ Operating Voltage : 1.8V ~ 5.5V
○ Operating Temperature : - 40℃ ~ 85/105℃
○ Key Features : High current port/ 12-bit ADC / ADC trigger function / DMA
○ Potential Application : Mass consumer & Small home appliances / Various controllers & modules / IoT products / Other home appliances
